Lottie Player Setup
Import Velt Components and Providers
Import the folllowing component from Velt:
VeltProvider
: Bootstraps Velt SDK.VeltComments
: Renders comments on the DOM.VeltCommentTool
: Enables or disables adding comments.VeltCommentPlayerTimeline
: Adds comments bubble over your player seek bar.VeltCommentsSidebar
: Adds a sidebar that shows all comments. Users can also search, filter & navigate to the comments from here.VeltSidebarButton
: Toggles the sidebar on/off.
import {
VeltProvider,
VeltComments,
VeltCommentTool,
VeltCommentPlayerTimeline,
VeltCommentsSidebar,
VeltSidebarButton
} from '@veltdev/react';
Add <VeltProvider> to the root of your app and pass in your API key.
<VeltProvider apiKey="YOUR_API_KEY">
<YourRootComponent />
</VeltProvider>
Authenticate your logged in user with the SDK.
In your auth component, call the identify()
method and pass in your User object in this format.
await client.identify(user);
Set the Document ID.
On the app page component where your player loads, call the setDocumentId()
method and pass in an unique ID that represents the file that the player loads.
client.setDocumentId('file-unique-id');
Add Velt Components in your app
5a. Add the VeltComments
component in the root of your app
Add the VeltComments
component to enable the Comment feature in your app.
Enable the follow attributes to be true
:
priority
: allows user to P0, P1, or P2 as priority. You can customize this list.autoCategorize
: allows AI to categorize comment as Question, Feedback, Bug, Other. You can customize this list.commentIndex
: shows a small icon showing index of the comment in order of creation.
<VeltComments priority={true} autoCategorize={true} commentIndex={true}/>
5b. Add the VeltCommentTool
component wherever you want your render the comment tool.
Note you can also provide your own button to this component.
<VeltCommentTool>
<button slot="button">
{/* your custom button (optional) */}
</button>
</VeltCommentTool>
5c. Place the VeltCommentPlayerTimeline
component as a sibling to your video player.
To show comment bubbles on your player seek bar, add the <VeltCommentPlayerTimeline>
component as a sibling to your video player component.
It will auto adjust to the same width as your video player.
<div>
<YourVideoPlayer/>
<VeltCommentPlayerTimeline/>
</div>
Right now we assume you have a maximum of one <VeltCommentPlayerTimeline>
component and one sibling video player component per documentID
Ensure that the parent container of <VeltCommentPlayerTimeline>
doesnt have CSS position value as ‘static’.
5d. Add the <VeltCommentsSidebar>
component.
(Optional) To embed the sidebar in your existing component, set embedMode
prop as true
.
<VeltCommentsSidebar embedMode={true}/>
5e. Add the <VeltSidebarButton>
component.
This will open or close the Comment Sidebar. Note you can also provide your own button to this component.
<VeltSidebarButton>
<div className='sidebar-custom-btn'>
{/* your custom button (optional) */}
</div>
</VeltSidebarButton>
Set the `totalMediaLength` on the `VeltCommentPlayerTimeline`
You can pass an integer to totalMediaLength
using props to represent the total number of frames or seconds in the video:
<VeltCommentPlayerTimeline totalMediaLength={120} />
Alternatively, you can set this using API method call. This is useful if you first need to grab the total frames from another method before setting it.
const commentElement = client.getCommentElement();
commentElement.setTotalMediaLength(120);
Subscribe to when the Comment Tool is activated by the User.
Add an event handler on where you originally placed <VeltCommentTool>
to handle onCommentModeChange
events.
Use this whenever the user clicks on the comment tool, to pause your player and set a new Location
in the Velt SDK.
Setting a Location
in the Velt SDK ensures that the comments are tied to that particular media frame or timestamp.
<VeltCommentTool onCommentModeChange={(mode) => onCommentModeChange(mode)} />
const onCommentModeChange = (mode) => {
// mode will be `true` if the user has activated the comment tool
// If the comment tool is active, pause the player and set the "location".
if (mode) {
// pause player
// See step 8 below for details
setLocation()
}
});
Set Velt Location
You can pass in a key value pair object that represents the current state of your player. If you are using the VeltCommentPlayerTimeline
component, ensure to set the current rounded frame or second in the special key currentMediaPosition
.
currentMediaPosition
is a protected keyword that is used to arrange the comment bubbles on top of the video player timeline in the correct spotconst setLocation = (client) => {
// set currentMediaPosition property on a Location object to represent the current frame
let location = {
currentMediaPosition : 120
}
//set the Location using the client
client.setLocation(location)
}
When the player is played, remove Velt `Location` to remove comments from the media.
Call removeLocation()
when your player starts playing:
const removeLocation = () => {
//remove the location, so the video player can play without comments appearing in frames
client.removeLocation()
}
Set your player's state when the user clicks on the comment.
Add the onCommentClick
event handler on the VeltCommentsSidebar
& VeltCommentPlayerTimeline
components you added earlier.
The event will give you back the location
object that you had set earlier.
You can use this object to update your player state and also update the SDK’s location
so that we can start rendering the comments associated with that location
.
10a. Handle it on the VeltCommentsSidebar
:
<VeltCommentsSidebar embedMode={true} onCommentClick={(event) => onCommentClick(event)} />
const onCommentClick = (event) => {
if (event) {
// Get the location object from the event.
const { location } = event;
if (location) {
// Get the media position where the comment was added.
const { currentMediaPosition } = location;
if (currentMediaPosition) {
// Pause the player.
// Seek to the given comment media position.
// Set the Velt Location to the clicked comment location.
client.setLocation(location);
}
}
}
}
10b. Handle it on the VeltCommentPlayerTimeline
:
<VeltCommentPlayerTimeline onCommentClick={(event) => onTimelineCommentClick(event)} />
const onTimelineCommentClick = (event) => {
if (event) {
// Get the location object from the event.
const { location } = event;
if (location) {
// Get the media position where the comment was added.
const { currentMediaPosition } = location;
if (currentMediaPosition) {
// Pause the player.
// Seek to the given comment media position.
// Set the Velt Location to the clicked comment location.
client.setLocation(location);
}
}
}
}
The clicked Comment data will be in the following format:
property | type | description |
---|---|---|
documentId | string | The document ID where the comment was added |
location | object | The location where the comment was added |
targetElementId | string | The DOM ID of the target element on which the comment was added |
context | Object | Any context data passed when the comment was added |
Additional Configurations
Allow comments only on certain elements
Provide a list of element DOM IDs where commenting should be allowed. Comments will be disabled for all other elements.
const commentElement = client.getCommentElement();
commentElement.allowedElementIds(['lottiePlayerContainer']);
